In SOLIDWORKS, dimensions drive the model geometry changing dimensions changes the shape of the model. You can create custom templates by opening existing templates (or any document file), setting options and inserting items (title blocks, base parts, and so on), then saving the documents as templates. SOLIDWORKS provides templates for parts, assemblies, and a variety of drawing styles. Visualize the 2D drawings folded up onto the sides of the glass box and projected into a 3D model. If you have a 2D model, or are designing in 2D, think in the opposite direction.
In 2D CAD systems, you think of projecting the views of a 3D model onto the sides of a glass box to visualize the 2D drawings. In SOLIDWORKS, you can open any number of part, assembly, or drawing documents at the same time: Just as an assembly consists of individual parts, a SOLIDWORKS part consists of individual features.
#Solidworks modeling software
The tools that are considered drawing tools in 2D CAD software are sketching tools in the SOLIDWORKS software. In SOLIDWORKS, drawings are the 2D documents that you create from 3D part or assembly models. The first three lessons of the SOLIDWORKS Tutorials cover basic part, assembly, and drawing concepts. In SOLIDWORKS, you design in a 3D environment, and you create 2D drawings based on the 3D model. In 2D CAD systems, you design in a 2D environment. 2D CAD systems and the SOLIDWORKS application have fundamentally different approaches.
